Taw qhia
Hgr rails hnyav -lub luag hauj lwm pob linear qhia ua los ntawm siab- steel zoo nrog kev kho deg. Lawv muaj lub siab rigidity, siab precision, thiab tsis tshua muaj kev sib txhuam. Lawv cov qauv tsim txhawb nqa cov khoom sib xws- bearing nyob rau hauv ntau cov lus qhia, muaj tus kheej -aligning peev xwm, muaj zog interchangeability, thiab yooj yim rau nruab.
Khoom Specifications
Cov koob no yog ua los ntawm cov hlau zoo - zoo, nrog rau kev kho qhov chaw uas muaj kev xeb thiab hnav tsis kam. Nws nta plaub - kab arc groove qauv ntawm nws cov tub ntxhais, ua ke nrog lub pob dov ncig lub cev, ua kom muaj kev sib txuam ntau- kev taw qhia kev thauj khoom los ntawm 45℃kev sib cuag lub kaum sab xis tsim. Nws muaj qhov tsis siv neeg nruab nrab muaj nuj nqi, uas tuaj yeem nqus cov teeb meem kev teeb tsa, thiab rigidity yog txhim kho los ntawm kev hloov kho ua ntej. Nws ua haujlwm nrog kev sib txhuam qis, qhov tseeb qhov chaw, thiab kev ua haujlwm du. Cov khoom txhawb nqa modular installation, muaj zog sib hloov, thiab yooj yim los tswj.
Qhov zoo ntawm HGR Rails:
1. HGR rails yog ua los ntawm high-hardness, siab- zoo steel, ua ke nrog cov txheej txheem kev txhim kho saum npoo. Lawv muaj kev hnav zoo heev thiab kev tiv thaiv corrosion, yooj yim tuav ntau yam hnyav- lub luag haujlwm kev lag luam, thiab tsis yooj yim deformed lossis puas nrog kev siv sijhawm ntev -.
2. Qhov tshwj xeeb plaub - kab arc groove tsim, ua ke nrog lub pob ua kom zoo dua qub, ua kom muaj zog txawm tias muaj kev faib tawm hauv plaub qhov kev taw qhia (nce, nqis, sab laug, thiab sab xis). Qhov kev txav yog du yam tsis muaj qhov nplaum, thiab qhov tseeb qhov chaw nyob deb tshaj li cov lus qhia zawv zawg ib txwm muaj.
3. Nruab nrog tus kheej tsis siv neeg -aligning muaj nuj nqi, nws muaj peev xwm cleverly nqus me ntsis installation yuam kev, tso cai rau kev sib dhos ceev yam tsis tau nquag recalibration, ho txo rau ntawm - site installation nyuaj thiab sij hawm tus nqi.
4. Lub dov kev sib txhuam qauv tsim tau zoo txo cov kev sib txhuam coefficient. Nws ua haujlwm ntsiag to, teb sai sai, thiab ib txhij txo qis kev siv hluav taws xob thiab cov khoom siv, txuas ntxiv lub neej kev pabcuam tag nrho ntawm cov khoom siv.
5. Tus qauv qauv qauv muab kev sib hloov zoo heev ntawm txoj kev tsheb ciav hlau thiab cov slider. Kev kho tom qab lossis kev hloov cov khoom siv yog qhov yooj yim thiab yooj yim, tsis tas yuav tsum muaj ntau tus neeg ua haujlwm lossis cov nqi ntxiv.
Daim Ntawv Thov Scope:Nrog rau siab rigidity, siab precision, thiab hnyav load-cov kabmob muaj peev xwm, HGR rails yog dav haum rau ntau yam kev lag luam scenarios. Lawv tuaj yeem siv rau hauv cov kab ntau lawm thiab cov khoom siv thauj khoom kom ntseeg tau tias cov khoom thauj khoom zoo thiab zoo; kuj tau sib xws nrog cov cuab yeej siv tshuab, cov chaw ua haujlwm dav dav, grinders, lathes, thiab ntau yam khoom siv tshuab.
Kev Pabcuam Qauv
Standard khoom Supply:
Muab rau hauv- cov khoom lag luam nrog kev xa khoom hauv 3-7 hnub;
Kev cai daws teeb meem:
Los ntawm kev xav tau kev sib txuas lus → kev daws teeb meem → qauv kuaj → ntau lawm, tag nrho cov txheej txheem tau txais kev txhawb nqa los ntawm kev sib cuag;
Tom qab-Kev Pabcuam Muag:
Muab cov kev taw qhia kev teeb tsa cov khoom, 1- xyoo warranty (tsis suav nrog kev puas tsuaj rau tib neeg), thiab kev pabcuam sai rau kev ua haujlwm tsis zoo.
Peb lub Hoobkas
Xuxin Automation: Koj Premier Ib -Stop Chaw tsim tshuaj paus rau siab -Precision Motion Cheebtsam
peb tshwj xeeb hauv R&D thiab kev tsim cov kev cai uas tsis yog - tus qauv coj cov ntsia hlau thiab txiv ntseej. Nrog rau peb lub xeev 13,000 m² - ntawm - lub - art facility, peb xa cov kev txhim khu kev lag luam automation kev daws teeb meem raws li koj qhov kev xav tau.
Chaw tsim khoom
Khoom siv Advanced
Pab neeg muaj kev paub
Tshaj tawm txhua xyoo
Vim li cas thiaj xaiv peb?
Exceptional Non-Txoj kev Customization peev xwm
Hauv -tsev R&D:Peb pawg kws tshaj lij engineering muaj ntau xyoo dhau los ntawm kev sib sib zog nqus -cov kws tshaj lij hauv kev lag luam txhuas thiab cov txiv ntoo.
Ntawm -Kev Xav Tau Kev Txhim Kho:Txawm hais tias koj xav tau kev coj ua tshwj xeeb, cov khoom siv tshwj xeeb, lossis cov qauv tsim, peb muab kev tsim khoom raws li koj qhov kev kos duab (PDF, CAD, lossis 3D qauv).
Rigorous Quality Control & Manufacturing
High -Precision Machining:Leveraging peb lub nkoj ntawm 80 CNC tshuab thiab precision sib tsoo chaw, peb xyuas kom meej txhua yam ua tiav micron - theem raug.
Full Supply Chain Integration:Los ntawm cov khoom siv raw khoom thiab kev kho cua sov mus rau kev sib tsoo thiab kev soj ntsuam zaum kawg, tag nrho cov txheej txheem tau ua tiav hauv -tsev. Qhov kawg no -rau- kawg tswj tau lav lub sij hawm ua cov hmoov txhuas ruaj khov thiab tsis muaj kev cuam tshuam zoo.
FAQ
1. Q: Yuav ua li cas tiv thaiv cov pob hlau los ntawm kev poob tawm thaum disassembling lub slider ntawm HGR rail?
A: Qhov no series ntawm rail sliders yog nruab nrog ib tug steel pob retainer. Thaum disassembling, lub slider yuav tsum tau rub tawm thaum uas tig mus thiab smoothly raws txoj kev tsheb ciav hlau tsis tilting los yog prying. Yog tias yuav tsum tau ua tiav kev sib cais, cov cuab yeej pabcuam tshwj xeeb tuaj yeem siv los txhawb nqa hauv qab ntawm lub slider los tiv thaiv cov khoom khaws cia los ntawm deforming, yog li tiv thaiv cov pob hlau los ntawm kev poob.
2. Q: Dab tsi yog cov ntsiab lus tseem ceeb uas yuav tsum tau saib xyuas thaum txuas HGR rail?
A: Thaum txuas ntxiv, ua qhov tseem ceeb ntawm kev siv cov ntsia hlau los ntawm tib pawg los xyuas kom meej qhov sib xws. Qhov kawg yuav tsum tau koom nrog yuav tsum tau ua raws li qhov sib txawv ntawm thermal expansion ntawm 0.03-0.05mm. Tom qab kev teeb tsa, xyuas qhov ncaj nrog ib qho ncaj kom ntseeg tau tias qhov yuam kev tsawg dua lossis sib npaug ntawm 0.01mm ib 100mm. Tsis tas li ntawd, qhov mounting qhov yuav tsum tau staggered kom tsis txhob cuam tshuam rau kev ua haujlwm du ntawm lub slider.
3. Q: Dab tsi yog qhov yuav tsum tau ua rau lub hauv paus nto thaum txhim kho HGR rail?
A: Lub hauv paus installation yuav tsum tiaj tus thiab huv si. Lub flatness kam rau ua yuav tsum tau kho raws li kev ua hauj lwm tej yam kev mob, feem ntau tsawg tshaj li los yog sib npaug zos rau 0.01mm ib 100mm rau ib txwm scenarios, thiab stricter rau hnyav load scenarios. Ua ntej kev teeb tsa, burrs thiab roj stains ntawm lub hauv paus yuav tsum tau muab tshem tawm, thiab shims tuaj yeem siv rau theem saum npoo yog tias tsim nyog los tiv thaiv kev ntxhov siab tsis sib xws ntawm txoj kev tsheb ciav hlau uas tuaj yeem ua rau deformation.
4. Q: Yuav tsum tau npaj dab tsi ua ntej rov siv HGR txoj kev tsheb ciav hlau uas tsis ua haujlwm ntev?
A: Ua ntej, tshem tawm cov dej noo- pov thawj ntim thiab ntxuav cov plua plav saum npoo nrog txhuam mos, tom qab ntawd so nrog dej tsis muaj ethanol. Txheeb xyuas qhov xwm txheej ntawm xeb- tiv thaiv roj thiab rov ua dua yog tias nws qhuav. Tom ntej no, manually txav lub slider rov qab los xyuas kom meej tias tsis muaj sticking, ces siv roj. Tom qab ob peb rotations uas tsis muaj qhov txawv txav, nws tuaj yeem muab rov qab siv.
Cim npe nrov: Tuam Tshoj hgr rails manufacturers, lwm tus neeg, Hoobkas
